Thin Wall Clear Plastic Tubes

TTHN


Thin Plastic Tubing
Plastic Poster Tubes and Mailing Tubes
  • Material: PETG (Polyethylene Terephthalate Glycol)
  • Cost Effective
  • Extruded and cut to the length you require for your application
  • Stocked in many popular lengths for immediate shipment.

TTHN – Product Media

Plastic Poster Tubes and Mailing Tubes Thin Wall Clear Plastic Tubes Thin Wall Plastic Posters Tubes Thin Wall Plastic Packaging Tubes Thin Plastic Tubing

Size Chart Thin Wall Round Tubes

Show Diagram

TTHN Size Chart

Default Inside Diameter
mm
Wall Thickness
mm
Diameter
mm
Length
mm
Stocked Length
mm
Box/Mini
QTY
Buy Online
1 CT5.3 TTHN 5.3 0.3 5.9 * 500 50
2 CT7.6 TTHN 7.6 0.3 8.2 * 500 50
3 CT10.7 TTHN 10.7 0.3 11.3 * 250 - 350 50
4 CT13.9 TTHN 13.9 0.3 14.5 * 200 - 300 25
5 CT16.2 TTHN 16.2 0.3 16.9 * 125 - 250 25
6 CT18.1 TTHN 18.1 0.4 18.8 * 75 - 250 25
7 CT20.5 TTHN 20.5 0.4 21.3 * 100 - 250 25
8 CT22.2 TTHN 22.2 0.4 23.0 * 200 25
9 CT23.9 TTHN 23.9 0.4 24.8 * 75 - 200 25
10 CT26.1 TTHN 26.1 0.4 27.0 * 150 25
11 CT27.8 TTHN 27.8 0.5 28.7 * 50 - 150 25
12 CT29.2 TTHN 29.2 0.5 30.1 * 100 25
13 CT30.9 TTHN 30.9 0.5 31.8 * 80 - 120 25
14 CT34.6 TTHN 34.6 0.5 35.5 * 50 - 150 18
15 CT36.5 TTHN 36.5 0.5 37.4 * 50 - 85 15
16 CT38.9 TTHN 38.9 0.5 39.8 * 65 15
17 CT41.8 TTHN 41.8 0.5 42.7 * 25 - 75 12
18 CT43.4 TTHN 43.4 0.5 44.5 * 50 - 60 10
19 CT46.2 TTHN 46.2 0.5 47.2 * 30 - 55 8
20 CT49.0 TTHN 49.0 0.5 50.0 * 45 8
21 CT52.6 TTHN 52.6 0.5 53.6 * 20 - 50 8
22 CT55.2 TTHN 55.2 0.5 56.2 * 35 8
23 CT58.9 TTHN 58.9 0.5 59.9 * 30 - 35 6
24 CT65.3 TTHN 65.3 0.5 66.3 * 20 - 30 5
25 CT70.9 TTHN 70.9 0.5 71.9 * 20 - 25 3
26 CT78.4 TTHN 78.4 0.6 79.6 * 15 - 30 3
27 CT90.7 TTHN 90.7 0.6 91.9 * 16 2
28 CT102.9 TTHN 102.9 0.7 104.3 * 6 - 12 2
Default Inside Diameter
mm
Wall Thickness
mm
Diameter
mm
Length
mm
Stocked Length
mm
Box/Mini
QTY
Buy Online
Legend:
- Add to Basket - Buy now - View Price

* Specify length when ordering.
Click Here to view our full selection of stocked lengths.


Tolerances

Tube Size Inside Diameter Wall Thickness Length
5mm - 70mm ±.08 ±.08 ±1.6
70mm - 90mm ±.13 ±.08 ±1.6
> 90mm ±.20 ±.10 ±1.6




Thin Wall Clear Plastic Tubes - Information

Our thin wall clear plastic tube packaging is recommended for lightweight or non-fragile items such as posters, housewares, confectionery products, novelties, toys or any items that require a unique, yet low-cost package. The thin wall clear plastic tubes provide the protection needed to house consumer products for retail sale, yet remain economical enough for packaging promotional items for handout at a trade show. Various styles of closures are available that feature standard or hanging capabilities.
Our thin wall clear plastic tubes are also available as a Sealed Bottom Clear Plastic Tube where a clear bottom is permanently adhered into the tube.

Our thin wall clear plastic tubes are:
  • Extruded and cut to the length you require for your application OR
  • Stocked in 1.2 metre lengths and sold in box quantities.
Contact Cleartec Packaging for more information on our clear plastic tubes.



RoHS
Contact Cleartec Packaging for more information on our clear plastic tubes.
