Heavy Wall Clear Plastic Tubes

0800 856 2466
Buy Now!

Heavy Wall Clear Plastic Tubes

THVY


Strong Plastic Packaging Tubes
Heavy Duty Plastic Tubes
  • Material: PETG (Polyethylene Terephthalate Glycol)
  • Durable and Strong
  • Extruded and cut to the length you require for your application
  • Stocked in 1.2m lengths and sold in box or mini-pack quantities

THVY – Product Media

Heavy Duty Plastic Tubes Heavy Wall Clear Plastic Tubes Heavy Duty Plastic Packaging Tubes

Size Chart Heavy Wall Round Tubes

Show Diagram

THVY Size Chart

Default Inside Diameter
mm
Wall Thickness
mm
Diameter
mm
Length
mm
Stocked Length
mm
Box/Mini
QTY
Buy Online
1 CT4.9 THVY 4.9 0.5 5.9 * 500 50
2 CT7.1 THVY 7.1 0.6 8.2 * 500 50
3 CT10.2 THVY 10.2 0.6 11.3 * 350 50
4 CT13.4 THVY 13.4 0.6 14.5 * 300 25
5 CT15.8 THVY 15.8 0.6 16.9 * 250 25
6 CT17.7 THVY 17.7 0.6 18.8 * 250 25
7 CT20.2 THVY 20.2 0.6 21.3 * 250 25
8 CT21.9 THVY 21.9 0.6 23.0 * 200 25
9 CT23.7 THVY 23.7 0.6 24.8 * 200 25
10 CT25.8 THVY 25.8 0.6 26.9 * 150 25
11 CT27.6 THVY 27.6 0.6 28.7 * 150 25
12 CT29.0 THVY 29.0 0.6 30.1 * 100 25
13 CT30.7 THVY 30.7 0.6 31.8 * 100 25
14 CT34.4 THVY 34.4 0.6 35.5 * 100 18
15 CT36.3 THVY 36.3 0.6 37.4 * 85 15
16 CT38.7 THVY 38.7 0.6 39.8 * 65 15
17 CT41.6 THVY 41.6 0.6 42.7 * 65 12
18 CT43.0 THVY 43.0 0.7 44.5 * 60 10
19 CT45.8 THVY 45.8 0.7 47.2 * 55 8
20 CT48.6 THVY 48.6 0.7 50.0 * 45 8
21 CT52.2 THVY 52.2 0.7 53.6 * 45 8
22 CT54.8 THVY 54.8 0.7 56.2 * 35 8
23 CT58.5 THVY 58.5 0.7 59.9 * 35 6
24 CT64.9 THVY 64.9 0.7 66.3 * 30 5
25 CT70.5 THVY 70.5 0.7 71.9 * 25 3
26 CT78.0 THVY 78.0 0.8 79.6 * 20 3
27 CT90.3 THVY 90.3 0.8 91.9 * 16 2
28 CT102.5 THVY 102.5 0.9 104.3 * 12 2
Default Inside Diameter
mm
Wall Thickness
mm
Diameter
mm
Length
mm
Stocked Length
mm
Box/Mini
QTY
Buy Online
Legend:
- Add to Basket - Buy now - View Price

* Specify length when ordering.
Click Here to view our full selection of stocked lengths.


Tolerances

Tube Size Diameter Wall Thickness Length
5mm - 70mm ±.08 ±.08 ±1.6
70mm - 90mm ±.13 ±.08 ±1.6
> 90mm ±.20 ±.10 ±1.6

In addition to heavy wall tubes, Cleartec Packaging also manufactures and supplies thin wall tubes, sealed bottom tubes and mailing tubes.




Heavy Wall Clear Plastic Tubes - Information

Our heavy wall clear plastic tube packaging is an ideal method for protecting heavy or fragile items such as welding rods, bearings, cutting tools, machined parts, medical devices or any items that require heavy-duty packaging.
Our tough heavy wall plastic tubes are reusable and offer unparalleled protection for your valuable merchandise.
The available closures and end caps that are available for our heavy wall tubes are vinyl caps and vinyl hanger caps.

In addition to packaging, these plastic tubes can be used as clear plastic mailing tubes, a part feeder and storage tube for automated assembly operations or even as a component part of your product.
Our heavy wall clear plastic tubes are:
  • Extruded and cut to the length you require for your application OR
  • Stocked in 1.2 metre lengths and sold in box quantities.

Contact Cleartec Packaging for more information on our clear plastic tubes.



RoHS
Contact Cleartec Packaging for more information on our clear plastic tubes.
